BALL COUPLERS
A-Frame Ball Couplers
These couplers are weldable and not for off the road use.
| Part # | Ball Size | GTW | VL | Wt. |
|---|---|---|---|---|
| 2405180 | 2" | 5,000 | 500 | 9 |
| 2405179 | 2-5/16" | 10,000 | 1,000 | 9 |
Weld-On Ball Couplers
These couplers are weldable and not for off the road use.
| Part # | Ball Size | GTW | VL | Wt. |
|---|---|---|---|---|
| 2405174 | 1-1/2" & 2" | 7,500 | 750 | 9 |
| 2405175 | 2-5/16" | 7,500 | 750 | 9 |
ABM Adjustable Couplers
Coupler fits with Wallace Forge Company Channels, Coupler’s holes drilled 2″ apart from the center of the holes. Use Grade 8 – 5/8″ Bolts.
| Part # | Model | Ball Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 2402178 | ABM-200 L | 1-7/8" & 2" | 10,000 | 1,000 | 12 |
| 2402179 | ABM-2516 L | 2-5/16" | 12,000 | 1,200 | 12 |
ABM Adjustable Coupler Replacement Parts
| Part # | Description |
|---|---|
| 2405189 | Loop Latch Assembly |
Yard Dog Couplers
These couplers are weldable and not for off the road use.
| Part # | Model | Ball Size | Inside Dia. of Ring | Ring Thickness | GTW | VL | Wt. |
|---|---|---|---|---|---|---|---|
| 2405205 | RCA48178 | 1 7/8" & 2" | 2" to 3" | 1" to 1 1/2" | 3,500 | 350 | 14 |
| 2405217 | RCA48516 | 2 5/16" | 2" to 3" | 1" to 1 1/2" | 3,500 | 350 | 14 |
Yard Dog Coupler Replacement Parts
| Part # | Description |
|---|---|
| 2405189 | Loop Latch Assembly |
Spring Loaded Adjustable Ball Couplers
The spring loaded coupler provides easy opening and a continuously tight fit on the hitch ball. Coupler fits with Wallace Forge Company Channels, Coupler’s holes drilled 2″ apart from the center of the holes.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 2425162 | 2-5/16" | 5/8" | 13,000 | 1,200 | 14 |
Light Duty Adjustable Ball Coupler
These couplers’ inner parts are heat treated. The couplers come with 3/8″ detent pins for added safety. Coupler fits with Wallace Forge Company Channels, Couplers’ holes drilled 2″ apart from the center of the hole.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 2422001 | 2" | 5/8" | 10,000 | 1,000 | 9.5 |
| 2425160 | 2-5/16" | 5/8" | 14,000 | 1,400 | 9.5 |
| Part # | Description |
|---|---|
| DTHP3840 | Detent Pin |
Medium Duty Adjustable Coupler
-Available for 2″ and 2 5/16″ hitch balls
-Auto-locking style provides easy attachment
Coupler fits with Wallace Forge Company Channels, Coupler’s holes drilled 2″ apart from the center of the holes.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| R20000 | 2" | 5/8" | 12,000 | 1,200 | 12 |
| R25160R | 2-5/16" | 5/8" | 20,000 | 2,000 | 12.75 |
| Part # | Description |
|---|---|
| R20000R | R20000 Latch |
| R25160R | R25160 Latch |
Heavy Duty Adjustable Coupler
-For 2 5/16″ hitch balls only
-Accepts three 5/8″ bolts
All three holes must be used to achieve 25,000 lb. capacity. Fit with Wallace Forge Company Channels, Coupler’s holes drilled 2″ apart from the center of the holes.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| R25163 | 2-5/16" | 5/8" | 25,000 | 2,500 | 10 |
14,000 lb. Rigid Mount Coupler
These couplers are weldable and not for off the road use.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 242516R | 2-5/16" | 5/8" | 14,000 | 1,400 | 10 |
| Part # | Description |
|---|---|
| DTHP3840 | Detent Pin |
20,000 lb. Rigid Mount Coupler
Auto-locking style coupler provides easy coupling attachment.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 20016 | 2-5/16" | 5/8" | 20,000 | 2,000 | 12.75 |
20,000 lb. Rigid Mount Coupler Replacement Parts
| Part # | Description |
|---|---|
| 20016R | Replacement Latch |
25,000 lb. Rigid Mount Coupler
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 20007 | 2-5/16" | 5/8" | 25,000 | 5,000 | 21 |
Channels
Gussets are available which provide the channel increased strength.
| Part # | Ball Size | Bolt Size | GTW | VL | Wt. |
|---|---|---|---|---|---|
| 2373142B | 3 Position | 8-1/2" | 30,000 | 3 | |
| 2376145B | 5 Position | 12-1/2" | 30,000 | 5 | |
| 2376146 | 3 Position | 7-1/2" | 20,000 | 3 | |
| 2376148 | 5 Position | 11-1/2" | 20,000 | 5 | |
| 2376140 | 6 Position | 14-1/2" | 20,000 | 6 | |
| 2376151 | 7 Position | 16-1/2" | 20,000 | 7 | |
| 2395165 | Grade 8 Bolt Kit | - | - | 4 |
